4 port GPON HGU

Overview :

  • GPT-2542GNUAC Gigabit-capable Passive Optical Network (GPON) Home Gateway Unit (HGU) Optical Network Unit (ONT) provides various integrated services through a single optical fiber for customers to support prevalent deployments of triple-play services such as data, video/High-definition Television (HDTV), VoIP and interactive games.
  • GPT-2542GNAUC features 802.11n and 802.11 ac technology to provide the ultimate solution for both speed and coverage. With 802.11ac wireless data rates of up to 1.3 Gbps, the GPT-2542GNAUC provides stable, reliable wireless connections for high-speed data and multimedia usages.
  • Advanced Quality of Service (QoS) ensures quality of triple-play services. Service providers can freely design their QoS policies and prioritize mission-critical services such as IPTV and VoIP based on their service plan offerings. This increases network efficiency and productivity that enable service providers to offer a real multi-play solution.

Specification :

HW Interface
  • WAN: One Giga optical interface (SC/APC)
  • LAN: Four 10/100/1000 auto MDI/MDI-X RJ-45 Interfaces
  • WLAN: Two 2x2 2.4G external antenna, Three 3x3 5G internal antenna
  • FXS: POTS port for 2 FXS
  • USB: Two USB 2.0 Host ports
  • LED indicators: Power, PON, Internet, Ethernet, USB, Wireless 2.4G, Wireless 5G, VOIP
  • Power supply: 12 DC, 2A
FW Feature:

GPON

  • Comply with Gigabit Passive Optical Network (GPON) standard: ITU-T G.984.1/G984.2/G984.3/G984.4
  • Support DS/US transmission rate to 2.488 Gbps/1.244 Gbps
  • Wavelength: 1490 nm downstream & 1310 nm upstream
  • Support 28 db loss budget (with class B+ optic)
  • Physical distance reach to 20 km
  • Support DBA (Dynamic Bandwidth Allocation)
  • GPON Encapsulation Method (GEM) supports Ethernet packet
  • Supports GEM header removal/ insertion and data extraction/ segmentation (GEM SAR)
  • Configurable AES DS and FEC DS/US
  • Support PLOAM handling: Including ONU-ID filtering, receiving of broadcast PLOAMs, and CRC check (DS)
  • Support up to 8 T-CONs each with priority queues (US)
Router/Bridge Features
  • IGMP v1/v2
  • DHCP
  • DNS
  • NAT/NAPT
WLAN
  • IEEE 802.11n/ac compliance
  • Frequency: 2.4/5 GHz
  • Data rate: 300Mbps/1.3Gbps
  • Static and dynamic WEP key (64/128 bit)
  • WPA/WPA-PSK & WPA2/WPA2-PSK
  • Multiple SSID (up to 4)
  • WPS (Wireless Protected Setup)
Management
  • Standard OMCI (G.984.4)
  • FTP/TFTP Server for firmware upgrade and romfile backup and restore
  • TR-069/TR-098 support
VoIP/Phone features
  • Voice codecs (coder/decoders) G.711 (a-law and µ-law), G.168 echo cancellation (8 ms ~ 16 ms)
  • DTMF detection and generation
  • 10 SIP accounts/phone numbers-freely assignable numbers to each phone port
  • Internal call
  • Call waiting, Call forwarding ,Call transferring and Call hold/call retrieve
  • Three-way conference
  • Second call/Adding an outgoing call
  • Switch between 2 active calls
QoS
  • Support DBA (Dynamic Bandwidth Allocation)
  • Support up to 32 T-CONTs each with priority queues
  • IEEE 802.1Q VLAN tagging and stacking support
  • Type of Service :TOS (RFC 791/1349)
USB
  • File sharing
Security
  •  Generic packet filter
  •  Firewall/DMZ
Physical Specification
  • Device dimensions: 215(L) x 139(W) x 49(H)
  • Item weight: 0.503kg
Environmental Specifications

Operating Environment

  • Temperature: 0°C to 40°C (32°F to 104°F)
  • Humidity: 20% to 85% RH (Non-condensing)

Storage Environment

  • Temperature: -20°C to 60°C (-4°F to 140°F)
  • Humidity: 20% to 90% RH (Non-condensing)

Certification

  • CE & FCC Compliance

Application Diagram :
